This cable is used for charging equipment for electric vehicles and charging ports, or for control systems of charging saturation,safety warning, and other control signal transfer functions of the vehicle charging and discharging.
Flex Resistance
Anti-EMI
Zero Halogen
Oil Resistance
Abrasion Resistance
High - speed Sharging
GB/T33594
-40~+90°℃
RoHS
CE
Tüv
| Conductor | Bare copper |
| Insulation | Special elastomer |
| Shield | Tinned annealed copper |
| Sheath | Special elastomer |
| Rated voltage | 1.0kV |
| Voltage withstand test | DC6kV/5min |
| Insulation resistance | >3670MΩ· km(20℃) |
Note: Above are the standard products also we can design on customer requirement.
