Mechanical life: no-load plug>10000times
Impact of external force: can afford 1m drop and 2T vehicle run over pressure
Shell material: thermoplastics, TPU
Retardant grade UL94-V0.
Pin: Copper alloy, silver + top of the thermoplastics
Operating temperature: - 30°C ~+50°C
The rated current: 32A, 50A, 63A
The rated voltage: 1000V
Insulation resistance: >2000MQΩ(DC1000V)
Pins temperature rise:<50K
Withstand voltage: 4500V(DC+/DC-/PE)
Contact impedance: 0.5mΩMax
| Product Type | EV Charging Cable |
| Rated Current | 32A, 50A, 63A |
| Rated Voltage | 1000V |
| Length | Regular 5m, can be customized |
| Color | Black or white |
| Warranty | 12 months |
| Certificate | CANS |
| Packaging Details | Standard export wooden case or carton, can be customized |
| Delivery Time(days) | Within 15 days, if qty is over 500pcs, to be negotiated |
