lMechanical life: no-load plug>10000times
lInsertion force:<140N
Shell material: thermoplastics, flame retardant grade UL94-0
Contact-tube: Copper alloy, silver-plated
Operating temperature: -30℃~+50℃
The rated current:80A, 125A, 200A, 250A
The rated voltage: 750V/1000V
Insulation resistance: >2000MΩ(DC1000V)
Pins temperature rise:<50K
Withstand voltage: 4500V (DC+/DC-/PE)
Contact impedance: 0.5mΩMax
Conform to the provisions and requirements of <Connection set for conductive charging of electric vehicles> GB/ T 20234.2-2015.
Have one or two PTC (PT1000) thermistor (can match with hela lock) ,have functions of signal feedback.
Beautiful appearance, prevention cap can be installed on the left side, the right side or the front of it.
Reliable material, flame retardant, presssure proof, wear-resisting, impact resistance, high oil proof.
Excellent protection performance, prodection grade achieved IP55 (working condition).
| Product Type | Rated Current | Cable Specifications | Note |
| AG-GBDC-C80S | 80A | H07BZ5-F2X20mm2+1x25mm2+2x4mm2+8x0.75mm2 | Wire length and tail end treatment according to customer configuration. |
| AG-GBDC-C125S | 125A | H07BZ5-F2X35mm2+1 x25mm2+2x4mm2+8x0.75mm? | |
| AG-GBDC-C200S | 200A | H07BZ5-F2X70mm2+1x25mm2+2x4mm2+8x0.75mm2 | |
| AG-GBDC-C250S | 250A | H07BZ5-F2X95mm2+1x25mm2+2x4mm2+8x0.75mm2 |
