AG robot cable acquires all safety and production certificates in cable filed: UL/c-UL, ROHS, CE, Core identification
It has more than 12 core color repetition (white, brown, green, yellow, gray, pink, blue, red, black, purple, orange, transparent),
Each number corresponds to an insulation color separation (can be combined and matched).
| Nominal cross section area | Conductor composition (diameter) | Diameter of insulation | Max.conductor DC resistance (20℃) | No.of pairs | Approx.overall diameter | Permissible current | Recommendation min.bend radius |
| AWG (mm²) | mm | mm | Ω/km | / | mm | A | mm |
| 21AWG0.5mm² | 3/33/0.08(1.14mm) | 1.94 | 46.9 | 2 | 6.8 | 7.6 | 40.8 |
| 3 | 7.1 | 7.5 | 42.6 | ||||
| 4 | 7.8 | 7.3 | 46.8 | ||||
| 6 | 9 | 6.6 | 54 | ||||
| 8 | 10.2 | 6.3 | 51.2 | ||||
| 12 | 12.9 | 5.8 | 77.4 | ||||
| 19AWG0.75mm² | 7/20/0.08(1.24mm) | 2.04 | 29.1 | 2 | 7 | 9.1 | 42 |
| 3 | 7.5 | 9 | 45 | ||||
| 4 | 8 | 8.6 | 48 | ||||
| 6 | 9.3 | 7.8 | 55 | ||||
| 8 | 10.9 | 7.3 | 65.4 | ||||
| 12 | 13.4 | 6.8 | 80.4 | ||||
| 17AWG1.0mm² | 7/30/0.08(1.50mm) | 2.3 | 18.3 | 2 | 7.7 | 10.5 | 46.2 |
| 3 | 8.1 | 10 | 48.6 | ||||
| 4 | 8.8 | 9.4 | 52.8 | ||||
| 6 | 10.1 | 8.6 | 60.6 | ||||
| 8 | 11.8 | 7.3 | 70.8 |
Note: Above are the standard products also we can on customer requirement.
